M21Z-5



M21Z-5

Opaque Woven Wire Mesh Pattern

gallery image ruler image
Notes: Product photography not to scale. Please download the woven wire spec sheet for more accurate size representation. Always confirm measurements with a physical sample. M21Z-005 – Architectural Woven Wire MeshM21Z-5
Transparency Model Specification Sheet

The smooth and wavy lines of the Banker Wire M21Z-5 opaque style woven wire mesh will excite the senses for your next architectural mesh project.

All of the helical wires are nested perfectly into one another during the weaving process to create a heavy, near-opaque cladding mesh that is unlike anything else in the market today.

Pattern Details

Percent Open:0.00%

Overall Thickness:0.315

Crimp Style:2DH3Z

Aspect Ratio:23.00:1

Opening Limitation:0.000

Weight:3.700 lbs./sq. ft.



Available Raw Materials: StainlessSteel_Icon2 PlainSteel_Icon2 WeatheringSteel_Icon2 Bronze_Icon2 Brass_Icon2 Click here for more information on Raw Materials

Available Secondary Finishes

Click here for more information on Secondary Finishes



M21Z-5 Photos



Projects Related To M21Z-5

Mill No. 1 SignageView Details

Notes:

Product photography not to scale. Please download the woven wire spec sheet for more accurate size representation. Always confirm measurements with a physical sample. All weight measurements are based on the specific density of mild (plain) steel. For conversion information, please refer to the Weights and Conversions section of our Woven Wire Basics Page or, contact us. It should be noted that architectural fabrics produced from very smooth, diamond drawn wires will, at times, exhibit striations of varying degrees of light and dark. These are not defects, but rather, part of the natural beauty of the material. Maximum dimensions may change based on alloy selection. Please contact us for additional details.
