S-18

right arrow
S-18 flat wire weave
S-18 flat wire weave
a arrow
S-18 flat wire mesh
Mid-Fill
Square

Pattern Details

Percent Open:
25.0%
Overall Thickness:
0.080
Aspect Ratio:
1.00
Crimp Style:
E1E1
Weight:
1.70
Opening Limitation:
0.300
Max A:
120inches
Max B:
60inches

Available Raw Materials:

  • 00 - Stainless Steel Wire Mesh

Available Secondary Finishes

Banker Wire offers a wide variety of secondary finishes through our outside vendors that can further enhance the aesthetic of any project. For more information, read about secondary finishes here.

PlatedPowder CoatUS10AUS10BPVD

Customization Options:

Customization of any wire mesh pattern is easy.  Banker Wire’s 100+ years of manufacturing experience makes it possible to create the wire mesh you envision right for your project.  We are likely to already have the tooling to produce what you are looking for and if not, we can design new tooling to make it within a few days.

lightbult icon

Customization of any wire mesh pattern is easy. Banker Wire's 100+ years of manufacturing experience makes it possible to create the wire mesh you envision right for your project. We are likely to already have the tooling to produce what you are looking for and if not, we can design new tooling to make it within a few days. Please contact us for more information.

800-523-6772
+44 (0) 1795 228 583
Notes

*Weight based on the specific density of mild (plain) steel **Maximum sphere diameter which will pass through opening Product specifications are subject to change. Product image is shown at 100% unless stated otherwise. For accuracy, specification sheet must be printed with no scaling. Measurements and data are approximate and should be confirmed with a physical sample.

Wire Mesh Pattern: S-18

S-18 flat wire mesh pattern is inspired by the many who have asked for a "basket weave." Banker delivers a beautiful mid-scale pattern that fits the bill.   Weaving with flat wire as opposed to round wire changes the visual characteristics of the wire mesh.  A lower percent open area is easier and in most cases easier to obtain.  Also, the broad surface area of the flat wire can capture the warmth of surrounding room lights and colors making it a unique material to design with.

Customization Options:

Customization of any wire mesh pattern is easy.  Banker Wire’s 100+ years of manufacturing experience makes it possible to create the wire mesh you envision right for your project.  We are likely to already have the tooling to produce what you are looking for and if not, we can design new tooling to make it within a few days.

800-523-6772
+44 (0) 1795 228 583

Notes

Product photography not to scale. Please download the wire mesh and woven wire spec sheet for more accurate size representation. Always confirm measurements with a physical sample.

All weight measurements are based on the specific density of mild (plain) steel. For conversion information, please refer to the Weights and Conversions section of our Woven Wire Basics Page or, contact us.

It should be noted that architectural fabrics produced from very smooth, diamond drawn wires will, at times, exhibit striations of varying degrees of light and dark. These are not defects, but rather, part of the natural beauty of the material.

Maximum dimensions may change based on alloy selection. Please contact us for additional details.
