Ornamental Welded Wire Mesh
Welded Wire Mesh For Architectural Applications
Banker Wire introduces a new line of large scale ornamental welded wire mesh patterns for architectural applications. The Banker Wire ornamental welded wire mesh panel collection includes multiple wire, square and rectangular repeating patterns that offer more visual interest than standard grids. All ornamental welded mesh patterns can be manufactured in the following metal alloys: Stainless (T304, T316), Plain Steel, Weathering Steel, and Pre-Galvanized. In addition, there are many secondary finishes that can be applied to further enhance the performance and visual characteristics of the mesh. Please call or email us if at any time there are questions. We are standing by to assist you in your next project.
WD-278
The WD-278 is a square repeating ornamental welded wire mesh pattern consisting of 2 wires every 6 inches. A Standard 48”x96” panel consists of 8 patterns by 16 patterns. A standard 60”x120” panel consists of 10 patterns by 20 patterns.
Do you have a question or would you like to see a sample of our Ornamental Welded Wire Mesh? Our knowledgeable sales staff can assist you with sample requests, quotes, and any additional questions you may have regarding this Ornamental welded wire mesh pattern. Call us toll-free at 1-800-523-6772, or visit our Request for Quote page.
Percent Open:87.60%
Overall Thickness:0.384 inches
Aspect Ratio:1.00:1
Weight:0.79 lbs./sq. ft.
Opening Limitation:3.808 inches
Panel Sizes: 48”x96" and 60”x120”
Available Raw Materials:
WD-299
The WD-299 is a square repeating welded wire mesh pattern of 3 wires every 7.5 inches. A standard 48"x96" panel consists of 6 patterns by 13 patterns. A standard 60"x120" panel consists of 8 patterns by 16 patterns.
Do you have a question or would you like to see a sample of our Ornamental Welded Wire Mesh? Our knowledgeable sales staff can assist you with sample requests, quotes, and any additional questions you may have regarding this Ornamental welded wire mesh pattern. Call us toll-free at 1-800-523-6772, or visit our Request for Quote page.
Percent Open:85.20%
Overall Thickness:0.384 inches
Aspect Ratio:1.00:1
Weight:0.99 lbs./sq. ft.
Opening Limitation:5.308 inches
Panel Sizes: 48”x96" and 60”x120”
Available Raw Materials:
WD-301
The WD-301 is a square repeating ornamental welded wire mesh pattern consisting of 2 wires every 6 inches. A standard 48”x96” panel consists of 8 patterns by 16 patterns. A standard 60” x 120” panel consists of 10 patterns by 20 patterns.
Do you have a question or would you like to see a sample of our Ornamental Welded Wire Mesh? Our knowledgeable sales staff can assist you with sample requests, quotes, and any additional questions you may have regarding this Ornamental welded wire mesh pattern. Call us toll-free at 1-800-523-6772, or visit our Request for Quote page.
Percent Open:87.60%
Overall Thickness:0.384 inches
Aspect Ratio:1.00:1
Weight:0.83 lbs./sq. ft.
Opening Limitation:4.808 inches
Panel Sizes: 48”x96" and 60”x120”
Available Raw Materials:
WD-303
The WD-303 is a square repeating ornamental welded wire mesh pattern consisting of 3 wires every 6 inches. A standard 48”x96” panel consists of 8 patterns by 16 patterns. A standard 60” x 120” panel consists of 10 patterns by 20 patterns.
Do you have a question or would you like to see a sample of our Ornamental Welded Wire Mesh? Our knowledgeable sales staff can assist you with sample requests, quotes, and any additional questions you may have regarding this Ornamental welded wire mesh pattern. Call us toll-free at 1-800-523-6772, or visit our Request for Quote page.
Percent Open:84.50%
Overall Thickness:0.324 inches
Aspect Ratio:1.00:1
Weight:0.84 lbs./sq. ft.
Opening Limitation:3.838 inches
Panel Sizes: 48”x96" and 60”x120”
Available Raw Materials:
WDZ-539
The WDZ-539 is a rectangular ornamental welded wire mesh pattern with a 7.5:1 aspect ratio. Cross wires are spaced every 1 inch while a trio of line wires are grouped every 7.50 inches. There are 6 groups of 3 line wires within a standard 48”x96” sheet. There are 8 groups of 3 line wires within a standard 60”x96” sheet.
Do you have a question or would you like to see a sample of our Ornamental Welded Wire Mesh? Our knowledgeable sales staff can assist you with sample requests, quotes, and any additional questions you may have regarding this Ornamental welded wire mesh pattern. Call us toll-free at 1-800-523-6772, or visit our Request for Quote page.
Percent Open:74.60%
Overall Thickness:0.384 inches
Aspect Ratio:7.50:1
Weight:1.74 lbs./sq. ft.
Opening Limitation:0.808 inches
Panel Sizes: 48”x96" and 60”x120”
Available Raw Materials:
WDZ-540
WDZ-540 is a rectangular ornamental welded wire mesh pattern with a 14.00:1 aspect ratio. Cross wires are spaced every 1 inch while the line wires are positioned in a 3,2,1/1,2,3 repeating sequence. Standard panel sizes offered are 48”x96” and 60”x120” sheets.
Do you have a question or would you like to see a sample of our Ornamental Welded Wire Mesh? Our knowledgeable sales staff can assist you with sample requests, quotes, and any additional questions you may have regarding this Ornamental welded wire mesh pattern. Call us toll-free at 1-800-523-6772, or visit our Request for Quote page.
Percent Open:76.00%
Overall Thickness:0.324 inches
Aspect Ratio:14.00:1
Weight:1.39 lbs./sq. ft.
Opening Limitation:0.838 inches
Panel Sizes: 48”x96" and 60”x120”
Available Raw Materials:
WDZ-542
WDZ-542 is a slightly rectangular ornamental welded wire mesh pattern with a 1.25:1 aspect ratio. There are 2 cross wires repeating every 6 inches and a line wire spacing consisting of 3 wires every 7.5 inches.
Do you have a question or would you like to see a sample of our Ornamental Welded Wire Mesh? Our knowledgeable sales staff can assist you with sample requests, quotes, and any additional questions you may have regarding this Ornamental welded wire mesh pattern. Call us toll-free at 1-800-523-6772, or visit our Request for Quote page.
Percent Open:85.70%
Overall Thickness:0.412 inches
Aspect Ratio:1.25:1
Weight:1.01 lbs./sq. ft.
Opening Limitation:5.338 inches
Panel Sizes: 48”x96" and 60”x120”
Available Raw Materials:
WDZ-545
WDZ-545 is a rectangular ornamental welded wire mesh pattern with a 4.00:1 aspect ratio. Cross wires are spaced every 2 inches while a trio of line wires are grouped every 8 inches. There are 6 groups of 3 line wires within a standard 48”x96” sheet. There are 7 groups of 2 line wires within a standard 60”x120” sheet.
Do you have a question or would you like to see a sample of our Ornamental Welded Wire Mesh? Our knowledgeable sales staff can assist you with sample requests, quotes, and any additional questions you may have regarding this Ornamental welded wire mesh pattern. Call us toll-free at 1-800-523-6772, or visit our Request for Quote page.
Percent Open:83.90%
Overall Thickness:0.384 inches
Aspect Ratio:4.00:1
Weight:1.04 lbs./sq. ft.
Opening Limitation:1.808 inches
Panel Sizes: 48”x96" and 60”x120”
Available Raw Materials:
WDZ-615
Sometimes simple is all that is needed. The high percent open area of the WDZ-615 makes sure the area is secure without drawing attention to it. The 2”x8” rectangular welded wire mesh pattern that has a 4.00:1 aspect ratio.
Do you have a question or would you like to see a sample of our Ornamental Welded Wire Mesh? Our knowledgeable sales staff can assist you with sample requests, quotes, and any additional questions you may have regarding this Ornamental welded wire mesh pattern. Call us toll-free at 1-800-523-6772, or visit our Request for Quote page.
Percent Open:88.20%
Overall Thickness:0.384 inches
Aspect Ratio:4.00:1
Weight:0.78 lbs./sq. ft.
Opening Limitation:1.808 inches
Panel Sizes: 48”x96" and 60”x120”
Available Raw Materials:
Notes
Tolerance for tail length is +/- 0.125". ■ Weight is based on the specific density of mild (plain) steel. ■ Opening limitation is the maximum sphere diameter which will pass through an opening. ■ Overall Thickness does not account for weld set-down. ■ Slight discoloration may appear on stainless steel at weld points. ■ Product specification are subject to change. ■ Measurements and data are approximate and should be confirmed with a physical sample.
